Fitting MJ-06-08 for Universal Several

One New Aftermarket Replacement JIC 37-Degree Male Rigid Straight Hydraulic Crimp Fitting (MJ-06-08)

This MJ-06-08 is a straight, rigid, 37-degree JIC male hydraulic crimp fitting designed to connect 3/8" (dash -06) hydraulic hose to a 1/2" JIC (dash -08) male thread port. It is a jump-size fitting commonly used in agricultural, construction, and lawn and garden hydraulic systems wherever a 3/8" hose must terminate at a 3/4"-16 JIC male thread connection. The steel construction and 37-degree flare seat provide a secure, leak-resistant crimp connection compatible with standard 1-wire and 2-wire braided hydraulic hose.

Specifications

• Fitting Type: JIC 37-degree Male Rigid Straight Crimp
• Hose Size: 3/8" ID (dash -06)
• Thread End: 1/2" JIC, dash -08
• Nominal Thread Size: 3/4"-16
• Male Thread O.D.: 3/4" (0.75")
• Fitting Shape: Straight
• Fitting Movement: Rigid
• Material: Steel

Compatible Applications

Universal-fit hydraulic crimp fitting suitable for agricultural equipment, construction equipment, and lawn and garden machinery using standard JIC hydraulic hose assemblies. Compatible with Weatherhead U Series, Parker, Dayco, Kurt, Kimball Midwest, and CSI crimper systems.

Replaces Part Number(s):

MJ-06-08, 06U-508, 103HY-8-6, 217-HY0608MJ, 256-06U508, 43V621, HY06-08MJ

New aftermarket replacement part - not remanufactured, not used.
