A-WK20-AI Woodruff Keys, 7/32 x 7/8

One New Aftermarket Replacement Woodruff Key - 7/32 x 7/8 in. (SAE No. 12 / ANSI 707)

This semi-circular (half-moon) Woodruff key measures 7/32 in. wide by 7/8 in. in diameter and is used to secure rotating hubs, gears, pulleys, and sprockets to shafts in agricultural equipment, construction machinery, lawn and garden equipment, and general industrial applications. The key seats into a matching semi-circular keyway machined into the shaft, locking the hub and shaft together to transmit torque and prevent relative rotation. It also serves as a designed fail-safe, intended to shear before more expensive components are damaged.

Specifications

• Width: 7/32 in. (0.2188 in.)
• Diameter: 7/8 in.
• Height: 0.359 in.
• Material: Carbon steel (C-1035)
• Profile: Flat-bottom, semi-circular (Woodruff / half-moon)
• Standard: ANSI/ASME B17.2; SAE J502; DIN 6888
• SAE Key Number: 12
• ANSI Key Number: 707

Compatible Applications

This is a standard ANSI-dimensioned Woodruff key suitable for use across a wide range of agricultural, construction, lawn and garden, and industrial equipment wherever a 7/32 x 7/8 in. Woodruff keyway is specified. Verify keyway dimensions on your shaft and hub before ordering.

Replaces Part Number(s):

A-WK20-AI, WK20

New aftermarket replacement part - not remanufactured, not used.
