A-HF6504 Filter, Hydraulic, Spin-On (QTY 1)
A-HF6504 Filter, Hydraulic, Spin-On (QTY 1)
Regular price
$80.48 USD
Regular price
Sale price
$80.48 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
One New Aftermarket Replacement Hydraulic Spin-On Filter - Replaces Fleetguard HF6504
This spin-on hydraulic filter is a direct replacement for the Fleetguard (Cummins Filtration) HF6504. It protects hydraulic systems by removing contaminants from hydraulic fluid, helping maintain reliable operation and extend the service life of pumps, valves, and other hydraulic components. Suitable for agriculture, construction, commercial vehicle, marine, mining, and power generation equipment applications.
Specifications
- Filter Type: Spin-On Hydraulic
- Overall Height: 147.57 mm (5.81 in.)
- Largest Outside Diameter: 93.22 mm (3.67 in.)
- Seam OD: 93.73 mm (3.69 in.)
- Gasket OD: 71.88 mm (2.83 in.)
- Gasket Inside Diameter: 62.48 mm (2.46 in.)
- Thread Size: 1-12 UNF-2B
- Bypass Valve Setting: 0 kPa (0 PSI)
- Filtration Rating: 10 micron (Beta=2), 23 micron (Beta=20), 35 micron (Beta=75)
- Weight: Approx. 1.50-1.55 lbs.
Replaces Part Number(s):
Fleetguard HF6504
Aftermarket Interchange Numbers
Fits Napa A02A25G9, Parker 929323, Parker 35-20B-1, Schroeder PZ25, Hydac MFE80-20BN/2, Hycon MFE80-20BN/2, Fairey Arlon FA35-CC25, MP Filtri 4163-25, PTI F4E-030-JC-B, Separation ST6504, Stauff SF-6504, Zinga ZAE-25
New aftermarket replacement part - not remanufactured, not used.
