A-HF35278 Filter, Hydraulic, Cartridge (QTY 1)

One New Aftermarket Replacement Hydraulic Cartridge Filter - Replaces Fleetguard HF35278

This hydraulic cartridge filter is a return-line hydraulic filter element used in agricultural tractors, construction equipment, and industrial machinery. It filters hydraulic fluid to protect pumps, valves, and actuators from contaminant damage. This aftermarket replacement is equivalent to Fleetguard HF35278 and its interchange Fits Donaldson P560527 (superseded by Fits Donaldson P160108).

Specifications

• Filter Type: Hydraulic cartridge (return line)
• Outer Diameter: 4.38 in (111.25 mm)
• Inner Diameter (bottom): 2.44 in (61.98 mm)
• Length: approx. 8.00 in (203 mm)
• Micron Rating: 25 nominal
• Direction of Flow: Inside to outside
• Maximum Temperature: 225 deg F
• Seal Material: Buna-N
• Media: Paper
• Recommended Changeout Pressure: 20 PSID

Compatible Equipment

Fits Massey Ferguson: Tractors and equipment using MF part 1051399M92, 1051399M91, 1051399M1, 1051399T91

Fits Caterpillar (Fits CAT): Equipment using Fits CAT part 3I0449

Ingersoll Rand: Equipment using IR part 35290295, 35328509, 35378464

Dresser / Galion: Equipment using part 136601, D136601

Doosan: Equipment using part 35328509

AGCO / Deutz: Equipment using part 1051399M92

Also used in power generation, mining, industrial, and other hydraulic system applications. Verify fitment against your equipment's OEM part number before ordering.

Replaces Part Number(s):

Fleetguard HF35278, HF6282; Fleetrite HFR835278, HFR86282; Fits Donaldson P560527, P160108; Baldwin PT760, PT76025; Wix 51531; Fits Napa 1531; Fram C6650, C6999, CH6650; Hastings LF217, P740; Luber-Finer LP2318; Fits Massey Ferguson 1051399M92, 1051399M91, 1051399M1, 1051399T91; Fits Caterpillar 3I0449; AGCO / Deutz 1051399M92; Ingersoll Rand 35290295, 35328509, 35378464; Dresser 136601; Doosan 35328509; Air Refiner ARH160108; Carquest 85531; Fits Napa 1531

New aftermarket replacement part - not remanufactured, not used.
