A-FF5206 Filter, Fuel, Spin-On (QTY 12)

Fits Case of 12 Aftermarket Replacement Fuel Filters, Spin-On - Fleetguard FF5206

This listing is for a Fits Case of 12 spin-on fuel filters replacing Fleetguard FF5206. These 20-micron spin-on fuel filters are designed to remove dirt, dust, and other contaminants from diesel fuel systems, helping to protect injectors and extend engine life. Commonly used on Detroit Diesel engines and medium-duty diesel applications, the FF5206 threads onto standard filter heads for quick, tool-friendly service. Note: for an upgraded filter design, use FF5333.

Specifications

• Filter Type: Spin-On Fuel Filter
• Overall Height: 175.57 mm (6.912 in)
• Largest OD: 93.13 mm (3.667 in)
• Seam OD: 93.62 mm (3.686 in)
• Gasket OD: 88.57 mm (3.487 in)
• Gasket Inside Diameter: 79.12 mm (3.115 in)
• Thread Size: 13/16-12 UNS-2B
• Standpipe: No
• Micron Rating (SAE J1858): 20 micron
• Efficiency (SAE J1858): 99%
• Quantity: 12 filters per Fits Case

Compatible Applications

Detroit Diesel: Engines using spin-on fuel filter heads (service part 3833200S head required for conversion to spin-on on some Detroit Diesel engines)

GMC: 25014342 application

AC: TP916D application

Replaces Part Number(s):

Fleetguard FF5206, Detroit Diesel 25014342, Detroit Diesel 23530707, GMC 25014342

Aftermarket Interchange Numbers

Baldwin BF581, Baldwin BF5810, Fits Donaldson P556916, Wix 33120, Luber-Finer LFP816F, LFP816FN, AC TP916D, AC TP916, Fits Donaldson P3823, Purolator PF902, Carquest 86120, ABPN10GFF5206, 9Y4418, RE26814B, AT41420, 465682C91, 12916, T916, T916D, TP816, TP91, 29463, 4347437, 853535036, FG767, 1992214, PS8479, 25010778, 9059910, 6439246

New aftermarket replacement part - not remanufactured, not used.
