A-C6290-16-16-W-AI (HW-C62) Code 62 Flange Head - 90� Elbow

One New Aftermarket Replacement Code 62 Flange Head 90-Degree Elbow Hydraulic Hose Fitting

This HW-C62 series Code 62 flange head 90-degree rigid elbow is a crimp-on hydraulic hose end fitting used to connect hydraulic hoses to SAE Code 62 4-bolt split-flange ports. The 90-degree bend routes hose in tight-clearance applications common in agricultural equipment, construction machinery, and industrial hydraulic systems. Part number C6290-16-16-W designates a straight (equal) 1-inch hose ID to 1-inch Code 62 flange connection with a skive-required W-series crimp end.

Specifications

• Series: HW-C62 (Code 62 Flange Head, 90-Degree Rigid Elbow)
• Configuration: 90-Degree Bent Tube, Rigid
• Hose ID: 1 inch (Dash -16)
• Flange Size: 1 inch (Dash -16)
• Crimp End: W-series (skiving required)
• Flange Standard: SAE Code 62 (High-Pressure 4-Bolt Split Flange)

Compatible Applications

Universal SAE Code 62 hydraulic fitting. Compatible with agricultural tractors, combines, construction equipment, skid steers, and any hydraulic system using SAE Code 62 4-bolt split-flange ports. Verify hose ID, flange size, and crimp ferrule compatibility before installation.

Replaces Part Number(s):

C6290-16-16-W, A-C6290-16-16-W-AI

New aftermarket replacement part - not remanufactured, not used.
