3V250 OPTIBELT INDUSTRIAL V-BELT 3/8" X 25"
3V250 OPTIBELT INDUSTRIAL V-BELT 3/8" X 25"
Couldn't load pickup availability
One New Aftermarket Replacement 3V/SPZ Wedge V-Belt (3V250) - Industrial Power Transmission
This 3V250 narrow wedge V-belt is a heavy-duty industrial power transmission belt used in a wide range of agricultural equipment, construction machinery, lawn and garden equipment, pumps, compressors, motors, and other industrial drives. The 3V (SPZ) narrow cross-section is engineered to transmit significantly more power than classical V-belt cross-sections in the same drive space, making it well suited for applications where space, weight, and horsepower capacity are critical factors.
Specifications
- Belt Section: 3V (SPZ / Narrow Wedge)
- Outside Circumference: 25 in (635 mm)
- Top Width: 3/8 in (9.7 mm)
- Belt Depth: approx. 0.31 in (8 mm)
- Belt Angle: 40 degrees
- Construction: Wrapped wedge belt
- Metric Equivalent: SPZ630
Compatible Applications
This 3V250 belt is a universal industrial V-belt suitable for use on tractors, motors, pumps, compressors, agricultural equipment, and a wide variety of power transmission drives that use a 3V or SPZ section sheave/groove.
Replaces Part Number(s):
3V250, S2945, S2954, V9L0089, 7087_Belt
Aftermarket Interchange Numbers
SPZ630 (metric equivalent), OTB40-0099
New aftermarket replacement part - not remanufactured, not used.
