A-MP-20-20-W-AI (HW-MP) Male NPTF Pipe - Rigid - Straight

One New Aftermarket Replacement HW-MP Male NPTF Pipe Crimp Fitting - Rigid Straight - MP-20-20-W

This HW-MP series Male NPTF Pipe crimp fitting (Rigid, Straight) connects 1-1/4" I.D. hydraulic hose to a 1-1/4" NPTF male pipe thread end. The W-style bite-to-wire crimp design bites into the steel wire reinforcement of the hose for a secure, leak-free connection in fluid power and hydraulic systems. The NPTF tapered thread seals by thread deformation for a dry-seal connection without the need for sealant tape. The rigid straight configuration maintains a fixed, non-rotating pipe end.

Specifications

• Style: HW-MP / W-Style Bite-to-Wire Crimp Fitting
• Configuration: Rigid Straight (non-swivel)
• Hose Inside Diameter: 1-1/4" (-20)
• Thread Type: Male NPTF (National Pipe Taper Fuel - Dry Seal)
• Thread Size: 1-1/4" x 11-1/2 TPI
• Internal Taper Seat: 30 degrees (compatible with female NPSM design)
• Compatible Hose Types: SAE 100R1SN, SAE 100R2SN, SAE 100R16S, SAE 100R17, 1-wire and 2-wire braided hose, all-size R12 non-skive, 4SH non-skive, industrial hose
• Dimensions (Kurt): A: 1-1/4", B: 4.15", C: 1.7", D: 1-11/16"
• Material: Carbon steel

Compatibility

This W-style fitting is compatible with many standard hydraulic crimpers. Interchanges with Weatherhead U-Series crimp fittings. Verify crimp diameter per crimper manufacturer specifications before assembly.

Replaces Part Number(s):

MP-20-20-W, A-MP-20-20-W-AI

Aftermarket Interchange Numbers

KTMP-20-20-W (Kurt Hydraulics), MP-20-20-W (A&I Products / HW Series), P-20-20-W

New aftermarket replacement part - not remanufactured, not used.
