A-H17505-AI Hub W/ Cups
A-H17505-AI Hub W/ Cups
Couldn't load pickup availability
One New Aftermarket Replacement Hub with Cups - 5-Bolt Implement/AG Hub
This aftermarket replacement hub with cups (bearing races pre-installed) is a 5-bolt agricultural and implement-style hub rated at 1,750 lbs. capacity. Designed for use on trailers, farm implements, and other agricultural equipment, this hub fits a standard #84-style spindle and arrives with inner and outer bearing cups already installed, making it a ready-to-assemble replacement for worn or damaged hubs on tillage tools, wagons, planters, and similar equipment.
Specifications
- Bolt Pattern: 5-bolt
- Bolt Circle Diameter: 4.50 in.
- Hub Pilot Diameter: 2.593 in.
- Load Capacity: 1,750 lbs.
- Bearing Cups: Inner and outer cups pre-installed
- Spindle Type: #84 (1-3/8 in. inner / 1-1/16 in. outer bearing)
Compatible Applications
Universal agricultural implement and trailer hub. Compatible with a wide range of farm equipment, pull-type implements, trailers, and utility equipment using a 5-bolt, 4.50 in. bolt circle hub pattern at 1,750 lb. capacity. Verify bolt pattern, pilot diameter, and spindle size before ordering.
Replaces Part Number(s):
H17505, A-H17505-AI
New aftermarket replacement part - not remanufactured, not used.
