A-C6145-08-08-W-AI (HW-C61) Code 61 Flange Head - 45� Elbow

One New Aftermarket Replacement SAE Code 61 Flange Head - 45-Degree Elbow Hydraulic Crimp Fitting

This SAE Code 61 flange head 45-degree elbow is a rigid hydraulic crimp fitting designed for 1/2" hose ID applications. The Code 61 four-bolt flange connection style is commonly used in high-pressure hydraulic systems on agricultural and construction equipment. Part number C6145-08-08-W (also sold under the AI prefix as A-C6145-08-08-W) connects a 1/2" hydraulic hose to a 1/2" SAE Code 61 flange port at a 45-degree angle, allowing routing in tight spaces where a straight fitting will not clear.

Specifications

• Fitting Type: SAE Code 61 Flange Head - 45-Degree Elbow (Rigid/Bent Tube)
• Hose ID: 1/2"
• Flange Port Size: 1/2" (Code 61)
• Connection Style: Four-Bolt Split Flange, SAE Code 61
• Elbow Angle: 45 degrees

Compatible Hose Types

Recommended for use with SAE 100R1AT, SAE 100R2AT, SAE 100R16, SAE 100R16S, and SAE 100R17 braided hydraulic hoses. Also compatible with 2-wire and 1-wire hydraulic hose assemblies.

Replaces / Interchange Part Number(s):

C6145-08-08-W, A-C6145-08-08-W, 08U-G41 (Weatherhead)

Aftermarket Interchange

Interchanges with Weatherhead U Series (08U-G41), Aeroquip FJ Series, Dayco SB Series, Dayco-Eastman HY Series, and Imperial-Eastman HU Series hydraulic hose fittings.

New aftermarket replacement part - not remanufactured, not used.
