A-2305WD-AI Bearing

Name: A-2305WD-AI Bearing
SKU: A-2305WD-AI
Price: 16.0 USD
Availability: InStock

A-2305WD-AI Bearing

$16.00 AUD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

One New Aftermarket Replacement 2305WD-AI Double Row Self-Aligning Ball Bearing

This 2305 series double-row self-aligning ball bearing is designed to tolerate shaft misalignment and deflection in agricultural, construction, lawn and garden, and general industrial machinery applications. The bearing features two rows of balls and a common spherical raceway in the outer ring, allowing the bearing to self-align and compensate for mounting errors or shaft flex during operation.

Specifications

Type: Double Row Self-Aligning Ball Bearing
Inner Diameter (Bore): 25 mm
Outer Diameter: 62 mm
Width: 24 mm
Dynamic Load Rating: 24,200 N
Static Load Rating: 6,550 N
Limiting Speed (Grease): 9,500 RPM
Limiting Speed (Oil): 12,000 RPM
Material: Chrome Steel
Bore Type: Cylindrical (straight bore)

Replaces Part Number(s):

A-2305WD-AI, 2305WD

Interchange cross-references: 2305, 2305M, 2305ETN9, 2305E-2RS1TN9, 2305-2RS-TV

New aftermarket replacement part - not remanufactured, not used.

Models This Part Fits:

4120, 2-105, 303, 1850, 674, 2-70, 1811, 6215, 651, 841, 600, 601, 541, Hydro 186, 200, 4100, 420, 851, 684, 4130 3 Cylinder, 3000, 2110, 4000 4 cylinder, 6070, 941, 2030, 1950, 310 Crawler, 3900, 580B, 4110, 185, 404, 2-85, 4030, 971, 580, 240, 4000, 901, 2600, 140, 504, 1655, 771, 200B, 3310, 430, 2100, 2310, 4130, 574, Dexta, 1750, 3150, 4140, 88, 741, 755, 2-44, 7815, 175, 701, Super 44, 3610, 811, 4200, 77, Super 90, 480 Loader, 65, 2-446, 820, 681, NAA, 6060, 2-62, 480, 5, 641, 4031, 203, 85, Hydro 84, 950, 3300, 231, 661, 840, 2131, 40, 383, 311, 3330, 205, 650, 871, 2130, 620, 770, 1010, 3190, 615, 881, 884, 204, 550, 2135, 135, 5190, 1881, 800, 860, 1800, 2500, 2-4413, 3910, 2-4414, 821, 310, 411B, 444, 2640, 480B, 1955, 2-4413L, 861, 1600, 584, 951, 330, 2300, 340, 2000 3 cylinder, 180, 62, Jubilee, 315, 3120, 531, 2150, 1821, 880, 2111, 230, 700, 440, 335, 2440, 454, 424, 4040, 2000, 390, 393, 631, 3100, 66, 3110, 900, 1855, 1871, 2000 4 cylinder, 4030 3 Cylinder, 2610, 78, 580 Loader, 1841, 1950T, 611, 981, 671, 1650, Super 55, 660, 501, 255, 2-4412, 1555, 4131, 375, 275, 4600, 90, 435, 621, 3600, 1801, 300B, 398, 3150 (UK), 960, 165, 285, 740, 961, 202, 399, 630, 640, 265, 850, 2031, 2120, 1550, 530, 4121

Additional Information:

Outside Diameter 2.328" Radius .05" Width .465"

Reference Numbers:

B12408, G57444, 651817R1, 8A1202B, D5NN1202A, 36723, JD8225, B12408, 327997, 70327997, LM67010, LM67010TIM, 70327997, 651817R1, 36723, D5NN1202A, 8A-1202B, 86980337, 354369X1, 15A10703, W102843A, 102843A
