Tune Up Kit Fits Case/International Harvester Replaces 21401D

$322.00 AUD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

One New Aftermarket Tune Up Kit

Tech Info:
-Kit Contains:
-(1) Ignition Kit
-Contains
-Points,
-Condensers &
-Rotors to service H-4 Magneto
-
-Replaces Part Number(s): 407017R91, 407017R92
-
-(4) Spark Plugs
-Standard Info
-Thread Size: 18mm
-7/8" Hex Shoulder
-Hex Size: 13/16" (20.6mm)
-Reach: 12mm (.472")
-Seat Type: Gasket
-Gap: .028" (0.7mm)
-Heat Range: 2
-Terminal Type: Removable Nut
-Resistor: No
-Thread Pitch: 1.5mm
-Center Electrode
-Type: Standard
-Material: Nickel
-Size: 2.5mm
-Projection: Non-Projected
-Ground Electrode
-Type: Standard
-Material: Nickel
-
-Replaces Part Number(s): G44840, 4012405C
-
-(1) Magneto Coil Cover
-
-Replaces Part Number(s): 47449DAX, 47449DAY
-
-(1) Distributor Cap
-Services H-4 Magneto,
-Clip Style
-
-Replaces Part Number(s): 407017R91, 407017R92
-
-(1) Gasket Set
-includes:
-Coil Cover Gasket
-Distributor Body Gasket
-Distributor Gear Cover Gasket
-Condenser Hole Cover Gasket
-Magneto Mounting Gasket
-
-Replaces Part Number(s): 359966R1, 47408D, 47453D, 48472DA, 49419D, 55780DD, 55780DE, E4226
-
-(1) Spark Plug Wiring Set (4 Cyl.)
-4 Cylinder
-
-(Non-tailored Straight Boot)
-
-(1) Magneto Coil
-
-Replaces Part Number(s): 21401D, 21401DAX, 361114R91, 47439D, 47439DA, 47439DAX, 57926DX, RW104

Made to Fit Case/International Harvester:
Tractor Models: A, I4, AV, Super A, Super A-1, Super AV-1, B, BN, C, Super C, H , HV, Super H, Super HV, I9, ID9, M, MD, Super M, Super MD, Super MDTA, Super MDV, MDV, Super MDV-TA, Super MTA, MV, Super MV, Super MVTA, O12, O4, O6, ODS6, OS4, OS6, T20, T5, T6, TD6, W12, W14, Super W4, W4, W40, Super W6, Super W6TA, W6, W6TA, Super W9, W9, Super WD6, WD6, Super WD9, Super WDR9, WD9, WDR9, WR9, 10-20, 15-30, 22-36, F12, F14, F20, Regular, 100, 130, 200, 230, 300, 350, 400, W400, 450, W450, 600, 650
Replaces Part Number(s): 21401D, 21401DAX, 361114R91, 47439D, 47439DA, 47439DAX, 57926DX, RW104

Models This Part Fits:

OS6, TD6, F14, Super MTA, O4, Super W4, Super A-1, 650, M, O12, Regular, A, W9, B, WD9, O6, AV, W14, Super WDR9, 15-30, Super MDTA, W4, 400, Super H, ID9, Super WD6, Super AV-1, H, 600, Super C, MV, ODS6, 22-36, 130, W12, Super MV, OS4, T6, I9, 230, WD6, W40, W6TA, Super W9, I4, Super MDV-TA, WDR9, F12, 450, 200, 350, MD, Super HV, F20, BN, C, T5, MDV, Super MDV, Super MVTA, Super M, Super W6TA, WR9, Super W6, Super WD9, 10-20, 100, W6, 300, W450, T20, Super A, W400, HV, Super MD

Additional Information:

Kit Contains: (1) Ignition Kit Contains Points, Condensers & Rotors to service H-4 Magneto Replaces Part Number(s): 407017R91, 407017R92 (4) Spark Plugs Standard Info Thread Size: 18mm 7/8" Hex Shoulder Hex Size: 13/16" (20.6mm) Reach: 12mm (.472") Seat Type: Gasket Gap: .028" (0.7mm) Heat Range: 2 Terminal Type: Removable Nut Resistor: No Thread Pitch: 1.5mm Center Electrode Type: Standard Material: Nickel Size: 2.5mm Projection: Non-Projected Ground Electrode Type: Standard Material: Nickel Replaces Part Number(s): G44840, 4012405C (1) Magneto Coil Cover Replaces Part Number(s): 47449DAX, 47449DAY (1) Distributor Cap Services H-4 Magneto, Clip Style Replaces Part Number(s): 407017R91, 407017R92 (1) Gasket Set includes: Coil Cover Gasket Distributor Body Gasket Distributor Gear Cover Gasket Condenser Hole Cover Gasket Magneto Mounting Gasket Replaces Part Number(s): 359966R1, 47408D, 47453D, 48472DA, 49419D, 55780DD, 55780DE, E4226 (1) Spark Plug Wiring Set (4 Cyl.) 4 Cylinder (Non-tailored Straight Boot) (1) Magneto Coil Replaces Part Number(s): 21401D, 21401DAX, 361114R91, 47439D, 47439DA, 47439DAX, 57926DX, RW104
